MM TS-A-L070-C16-T10-CH
MULTI-MASTER cylindrical shanks for interchangeable milling heads.
Price: Log in For Price
| Connection Thread Nominal Size Workpiece Side (THSZWS) | T10 | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 16 mm | Rotational Speed Maximum (RPMX) | 39420 Rev/min |
| Overall Length (OAL) | 70 mm | Body Material | Steel |
| Tool Type | Cylindrical Shanks | Connection Code Machine Side (CCMS) | Cylindrical |
| Body Diameter (BD) | 15.3 mm | Unit | M |
Product Features
| FamilyDesc | MULTI-MASTER cylindrical shanks for interchangeable milling heads. | FamilyName | MM TS-A |
| Remarks | For adaptation click on More Info Do not apply lubricant to the threaded connection. | BrandName | Iscar |
| COO | Israel |
Shipping Info
PackageWeight
0.1060
Name
Solid End Mill Shanks
FamilyName
MM TS-A
BrandName
Iscar
